This also applies to automotive lighting if the LED lights are outdoors or indoors or on the back or on the front of the car.
Depending on the application, sometimes it’s better to use linear drivers instead of switching drivers. Every automotive lighting solution includes a distinctive LED driver they are used for energy saving solutions, visibility, etc.
The LED automotive lighting market is actively growing. Bleeders are not included in the design passive damping and a single winding inductor are used for TRIAC management.
An EMI pi filter blocks differential and common mode noise. Its design offers a wide input (90 VAC – 308 VAC) and output voltage range operation. The 735V integrated MOSFET ensures sufficient overvoltage protection during line surge occurrence. It is compatible with TRIAC dimmers capable of delivering up to 22 watts. This buck LED driver IC has a buck topology with a power factor higher than 0.9. For example, Power Integrations offers the LYTSwitch-7 (Fig. However, an array of products exist that can be used in this application. One of the challenges of dimming is pairing LED lights with TRIAC or phase-cut dimmers that were never designed for LEDs. This dimmable LED driver is designed to power a 60 V LED voltage string at 125 mA output current from an input voltage of 90 V ac to 300 V ac. This is a schematic of LED driver configured as a low-side buck utilizing the LYT7503D from the LYTSwitch-7 family of ICs. In contrast, pulse width modulation (PWM) dimming is accomplished by adjusting the nominal LED current by switching ON and OFF at a sufficiently high frequency to avoid a flickering effect.ġ. This approach is not acceptable in many applications because there is a color shift with current variation. The analog voltage is adjusted and the LED current is changed to achieve dimming. There are two popular methods for dimming LEDs in switch-mode driver circuits: analog and Pulse-Width Modulation (PWM) dimming.Īnalog Dimming refers to the adjustment of the nominal LED current. Dimming of small-form-factor lamps.įew LED applications use the ON and OFF setting, as dimming helps to reduce energy consumption. Here we present five different LED driver products for the major developments in LED applications mentioned earlier: 1. Some of the major developments in LED applications that have occurred and continue to evolve are as follows: dimming LED lamps, automotive lighting, LED signage, smartphone backlighting, and TV backlighting. An appropriate driver generates a successful application. The steady growth of LED lighting technology has generated a wide range of LED-driver IC options in the semiconductor market. LED drivers also aid efforts to meet new energy requirements (e.g., Energy Star). LED drivers are electrical devices that prevent damage to LEDs by regulating the forward voltage (V F) of the LED that changes with temperature, avoiding thermal runaway while delivering a constant current to the LED. But for LEDs to perform at their best they need the assistance of LED drivers to provide better efficiency, reliability, and longevity. Light-emitting diodes (LEDs) are semiconductor devices that emit light when an electrical current passes through semiconductor materials. This file type includes high resolution graphics and schematics when applicable.
